Basic Info

Model No.: BODA-104

Impeller Number: Single-Stage Pump

Working Pressure: High Pressure Pump

Influent Type of Impeller: Single Suction Pump

Position of Pump Shaft: Horizontal Pump

Pump Casing Combined: Verticaljoint Surface Pump

Mounting Height: Since Irrigation Centrifugal Pumps

Impeller: Open

Usage: Pump

Product Name: S Series Double Suction Pump

Additional Info

Packaging: wooden box

Productivity: 500

Brand: BODA

Transportation: Ocean,Land,Air

Place of Origin: china

Supply Ability: 500

Certificate: ISO9901

HS Code: 4101201190

Port: Tianjin,Qingdao,Shanghai

Product Description

product description

      The pump is the advanced experience of introducing high-efficiency energy-saving and non-clogging sewage pump, combined with the technical strength of the unit, and all the performance indicators have reached the level of similar products of the national standard. Due to the unique single-channel impeller and dynamic seal, two sets of special materials are used for the cemented carbide mechanical seal. The motor is separated by oil chamber, which has no clogging, high efficiency and remarkable energy saving. It is a new product of pump upgrading in China, and is well received by users.

Features

1The unique single-blade or double-bladed impeller structure greatly improves the dirt passing ability, and can effectively pass 5 times of the fiber diameter of the pump and the solid particles with a diameter of about 50% of the pump diameter.

2 The mechanical seal adopts a new type of hard and corrosion-resistant tungsten carbide material, and at the same time, the seal is improved into a double-end seal, so that it can be operated in the oil chamber for a long time, and the pump can be safely operated continuously for more than 8000 hours.

3 The overall structure is compact, small in size, small in noise, remarkable in energy saving effect, convenient in maintenance, no need to build a pump room, and can work in submerged water, greatly reducing the project cost.

4 The pump seal oil chamber is equipped with a high-precision anti-interference water leakage detection sensor, and a thermal element is embedded in the stator winding to absolutely protect the pump motor.

5 According to the user's needs, it can be equipped with automatic safety protection control cabinet to absolutely protect the pump from water leakage, leakage, overload and over temperature, which improves the safety and reliability of the product.

6Float switch can automatically control the start and stop of the pump according to the required liquid level change, no need for special care, it is very convenient to use.

7 can be equipped with double-rail automatic coupling installation system according to user needs, which brings great convenience to installation and maintenance, and people do not have to enter the sump for this purpose.

8 can be used within the full lift range to ensure that the motor will not be overloaded.

9 There are two different installation methods, fixed automatic coupling installation system, mobile free installation system.

Scope of application

     GW series non-blocking pipeline sewage pump is suitable for the discharge of serious polluted wastewater from the factory, the sewage discharge station in the main residential area, the water distribution system of the urban sewage treatment plant,  the water supply equipment of the water supply plant, the hospital, the hotel. Sewage discharge, municipal engineering construction sites, mine supporting machines, rural biogas digesters, farmland irrigation and other industries, transporting granular sewage, dirt, can also be used for clean water and with weak corrosive media.

Conditions of Use

A. The operating temperature of the pump is ≤40°C, the humidity is ≤95%; the altitude is ≤1000m.

B. The medium temperature does not exceed 60 ° C, and the medium weight is 1 to 1.3 kg / dm 3 .

C, the use of cast iron material range PH5 ~ 9.

D, stainless steel material can use general corrosive media.

E. The use environment should not exceed 1000 meters above sea level. When the above conditions are exceeded, it should be submitted at the time of ordering to provide you with more reliable products.

Note: If the user has special temperature, medium and other requirements, please specify the details of the transport medium when ordering, so that the unit can provide more reliable products.

Features

1. Adopting double-blade impeller structure, greatly improving the ability of dirt to pass.

2. The mechanical seal adopts a new type of grinding pair, and it is put into the oil chamber for a long time;

3. The overall structure is compact, the volume is small, the sound is small, the energy saving effect is remarkable, the maintenance is convenient, and the user is convenient to replace;

4. The automatic control cabinet can automatically control the over-motion and stop of the pump according to the required liquefaction change, without special care, and is extremely convenient to use;

5, can be equipped according to the user's needs, it provides great convenience for installation and maintenance, people can enter the sump without having to do this;

6, can be used within the design range, and ensure that the motor will not overload;

7. If the pump is equipped with an outdoor motor, there is no need to build a pump room, which can be directly installed and used outdoors to save money;
