Basic Info

Model No.: BODA-162

Product Name: S Series Double Suction Pump

Additional Info

Packaging: wooden box

Productivity: 500

Brand: BODA

Transportation: Ocean,Land,Air

Place of Origin: china

Supply Ability: 500

Certificate: ISO9901

HS Code: 4101201190

Port: Tianjin,Qingdao,Shanghai

Product Description

I-1B series thick slurry pump

1. The thick slurry pump can transport high concentration and high viscosity (<10000PaS) and suspended slurry containing particles.

2. The slurry flow is stable and there is no overcurrent, pulsation, stirring and shearing.

3. The discharge pressure of the thick slurry pump is independent of the rotation speed, and the low discharge flow can also maintain a high discharge pressure.

4. The flow rate of the thick slurry pump is proportional to the rotational speed, and the flow rate can be adjusted by the shifting mechanism or the high speed motor.

5. The thick slurry pump has strong self-priming ability, and the liquid flow direction is changed by the rotation direction of the pump, which is suitable for the occasion where the pipeline needs to be reversed and forwardly flushed.

6. The thick slurry pump runs smoothly, with small vibration and noise.

7. The slurry pump has a simple structure, convenient disassembly and assembly, and convenient maintenance.

Structural material type

I-1B type thick slurry pump: shell cast iron, transmission parts are general steel, suitable for general neutral thick slurry transportation.

I-1B type thick slurry pump: The transmission parts (spindle, screw and winding shaft) are made of stainless steel, which is suitable for general micro acid and alkali slurry transportation.

Type I-1B thick slurry pump: The pump housing of the transmission piece and the joint slurry is made of stainless steel, which is suitable for the transportation of food, pharmaceutical and corrosive slurry.

Rubber bushings are generally wear-resistant rubber, food rubber and oil resistant rubber for users to choose.

The transmission mode has direct drive between the motor and the pump shaft. The motor is directly driven by the reducer and the pump and the motor is driven by the V-belt pulley and the pump shaft for the user to purchase.

The motor is equipped with a general enclosed, explosion-proof and electromagnetic speed control motor.

Thick slurry pump range

The thick slurry pump is widely used in chemical, pharmaceutical, brewing, paper making, food and other units.

1. The thick slurry pump can transport high concentration and high viscosity (<10000PaS) and suspended slurry containing particles.

2. The slurry pump delivers stable liquid flow without overcurrent, pulsation, stirring and shearing.

3. The discharge pressure of the thick slurry pump is independent of the rotation speed, and the low discharge flow can also maintain a high discharge pressure.

4. The flow rate of the thick slurry pump is proportional to the rotational speed, and the flow rate can be adjusted by the shifting mechanism or the high speed motor.

5. The thick slurry pump has strong self-priming ability, and the liquid flow direction is changed by the rotation direction of the pump, which is suitable for the occasion where the pipeline needs to be reversed and forwardly flushed.

6. The thick slurry pump runs smoothly, with low vibration and noise.

7. The thick slurry pump has a simple structure, convenient disassembly and assembly, and convenient maintenance.

      The screw pump (dense pump) is a new type of liquid conveying machine. It has the advantages of simple structure, safe and reliable work, convenient use and maintenance, continuous and uniform discharge, and stable pressure. The thick-slurry pump produced by our company is made of high-quality acid-resistant stainless steel. The liner is made of non-toxic and odorless rubber. The working temperature can reach 120 °C. It can be used to transport food slurry and viscosity 10,000 Poisca·s. A solution slurry containing solid particles or blisters, a corrosive medium for the suspension. Widely used in food, metallurgy, chemical, printing and dyeing, paper, ceramics and other industrial sectors.
