Basic Info

Model No.: TZS

Impeller Number: Single-Stage Pump

Working Pressure: Low Pressure Pump

Influent Type of Impeller: Single Suction Pump

Position of Pump Shaft: Horizontal Pump

Pump Casing Combined: Horizontal Split Pumps

Mounting Height: Suction Centrifugal

Impeller: Closed

Usage: Pumps

Application: Mining, Steel Factory, Sand Transportation

Material:: A05, A07, A49

Theory:: Centrifugal Pump

Shaft Seal:: Packing Seal, Mechanical Seal, Expeller Seal

Application 1:: Mine And Miner Processing

Medium Concentration: Max Cv Or CW 80% At Heavy Duty

Fuel:: Electric Or Fuel Driven By Engine

Power:: Electric

Usage:: Slurry, Sludge, Mud And Dirty Water In Mining

Pump Name: Horizontal Centrifugal Heavy Duty Mining Slurry Pu

Additional Info

Packaging: In wooden case

Productivity: 500 sets per month

Brand: Boda

Transportation: Ocean,Land,Air

Place of Origin: China

Supply Ability: 300 sets per month

Certificate: ISO90001

HS Code: 8413709990

Port: Xingang,Horgos,SHANGHAI

Product Description

Application and Features:

Type BM, BH,  slurry pumps are cantilevered, horizontal, centrifugal slurry pumps.They are designed for the handling highly abrasive, high density slurries in the metallurgical, mining, coal, power, building material and other industrial departments etc.The pumps of this type also may be installed in multistage series.

The frame plates for the type BM, BH pumps have replaceable wear-resistant metal liners or rubber liners.The impellers are made of wear-resistant metal or rubber.

The shaft seals for type BM, BH, pumps may be adoptable of gland seal or expeller seal.The discharge branch can be positioned at intervals of 45 degrees by request and oriented to any eight positions to suit installations and applications.

Brief Introcustion to Pump Type Selection:

Refering to the performance curves of the pump the selected capacity range should be as follows:

Pump Type BM, BH: 40-80% for higher density, strong abrasive slurries

                                  40-80% for medium density, medium abrasive slurries

                                 40-120% for lower density, lower abrasive slurries
