200TZM Diesel engine Sand dredge Pump
| Payment Type: | L/C,T/T,Western Union |
|---|---|
| Incoterm: | FOB,CFR,CIF |
| Min. Order: | 1 Set/Sets |
| Delivery Time: | 20 Days |
Basic Info
Model No.: TZM
Working Pressure: High Pressure Pump
Position Of Pump Shaft: Horizontal Pump
Impeller: Closed
Material: A05 A07 A49
Origin: Shijiazhuang
Drive Type:: CV, DC, Zv, Cr
Color: As Your Requirement
Package: In Woodenc Case Or As Your Requirement
Power: Electric Or Diesel
Model No.: BM BH
Additional Info
Packaging: In Wooden case or as your requirement
Productivity: 300sets/month
Brand: Boda
Transportation: Ocean,Land,Air
Place of Origin: Shijiazhuang
Supply Ability: 100 sets/ month
Certificate: ISO
HS Code: 8413709990
Product Description
200TZM Diesel engine Sand dredge Pump /Sand Dredging Pump / Diesel Engine Sand Pump / Diesel Engine Dredging Pump
InDiesel engine Sand dredge Pump troduction:
200TZM Diesel engine Sand dredge Pump
Durable diesel engine mud and sand dredging pump with lowest price
Sand pump are designed for sucking sand and gravel from river/lake/sea and so on.
It also can transport sludge in the pond,sewage&dross in the mining and industry production.
It is the ideal energysaving auxiliary pump of sand pumping barge,water well drilling rig and
other basic engineering equipment.
We can supply various size of diesel engine mud and sand dredging pump with lowest price.
The Features:
1. The frame plates for Diesel engine Sand dredge Pump have replaceable wear-resistant metal liners or rubber liners. The impellers are made of wear-resistant metal or rubber. The frame plate liner and impeller for TZH pump are adoptable of hard metal only.
2. Bearing assembly use cylindrical structure,adjusting the space between impeller and front liner easily, being removed completely when being repaired. Bearing assembly use grease lubrication.
3. The shaft seal could use the packing seal, expeller seal and mechanical seal.
4. The discharge branch can be positioned at intervals of 45 degrees by request and oriented to any eight positions to suit installations and applications.
5. There are the drive types, such as V belt drive, gear reducer drive, fluid coupling drive, frequency conversion drive devices.
6. Wide performance, good NPSH and high efficiency. The pump of this type may be installed in multistage series to meet the delivery for long distance.
Application:
TZS, TZH pumps are used to pump high-hardness, strong-corrosion and high-concentration liquids that contain suspended solid particles, such as finished ores, refuse ores, ashes, cinders, cements, mud, mineral stones and etc. in the industries of metallurgy, mining, coal, power, building material and etc. The temperature of the pumped solid-liquid mixture should be ≤80oC, and the weight concentration should be ≤60.
Slurry Pump Construction
Pump Body: Cast Iron/Grey Iron
Front Cover: High Chrome alloy/ Rubber lined
Impeller: High Chrome alloy/ Rubber lined
Mechanical Seal: Carbon/Ceramic/Stainless Steel
Motor Housing: Alloy Aluminum
Shaft: Carbon Steel/Stainless Steel/High Frequency Wedding Shaft
Insulation: Class B / Class F
Protection: IP54 / IP55/IP67
Cooling: water cooling
Mining Tailing Slurry Pump Performance Table:
|
Type
|
Allowable Mating Max.Power(kw)
|
Clear Water Performance
|
Impeller
|
||||||
|
Capacity Q
|
Head
H
(m) |
Speed
n
(r/min) |
Max EFF η(%)
|
NPSH)
(m) |
No of Vanes
|
Impel Dia(mm)
|
|||
|
(m3/h)
|
(L/S)
|
||||||||
|
20TZS-PB
|
15
|
12.6-28.8
|
3.5-8
|
6-68
|
1200-3800
|
40
|
2-4
|
5
|
152
|
|
40TZS-PB
|
15
|
32.4-72
|
9-20
|
6-58
|
1200-3200
|
45
|
3.5-8
|
5
|
184
|
|
50TZS-PC
|
30
|
39.6-86.4
|
11-24
|
12-64
|
1300-2700
|
55
|
4-6
|
5
|
214
|
|
75TZS-PC
|
30
|
86.4-198
|
24-55
|
9-52
|
1000-2200
|
71
|
4-6
|
5
|
245
|
|
75TZS-PD
|
60
|
||||||||
|
100TZS-PD
|
60
|
162-360
|
45-100
|
12-56
|
800-1550
|
65
|
5-8
|
5
|
365
|
|
100TZS-PE
|
120
|
||||||||
|
100TZS-PD
|
60
|
180-396
|
50-110
|
7-61
|
600-1600
|
55
|
3-8
|
4
|
372
|
|
100TZS-PE
|
120
|
||||||||
|
150TZS-PE
|
120
|
360-828
|
100-230
|
10-61
|
500-1140
|
72
|
2-9
|
5
|
510
|
|
150TZS-PR
|
300
|
||||||||
|
150TZS-PE
|
120
|
360-828
|
100-230
|
7-52
|
400-1000
|
70
|
2.5-6
|
4
|
536
|
|
150TZS-PR
|
300
|
360-828
|
100-230
|
7-52
|
400-1000
|
70
|
2.5-6
|
4
|
536
|
|
200TZS-PST
|
560
|
612-1368
|
170-380
|
11-61
|
400-850
|
71
|
4-10
|
5
|
686
|
|
250TZS-PST
|
560
|
936-1980
|
260-550
|
7-68
|
300-800
|
82
|
6
|
5
|
762
|
|
300TZS-PST
|
560
|
1260-2772
|
350-770
|
13-63
|
300-600
|
77
|
3-10
|
5
|
965
|
|
350TZS-PST
|
560
|
1368-3060
|
380-850
|
11-63
|
250-550
|
79
|
4-10
|
5
|
1067
|
|
350TZS-PTU
|
1200
|
||||||||
|
200TZM-PE
|
120
|
540-1440
|
150-400
|
14-60
|
600-1100
|
73
|
4-10
|
5
|
549
|
Mining Tailing Slurry Pumps Structure:
Mining Tailing Slurry Pumps Application:
